FM-SA8

Quantity:
Availability:





Inquire Add to Basket

Product Description

Ambient Centrifugal model

Centrifugal structure ensure high air velocity

Aesthetically pleasing 3D design suitable for most commercial application

Customizable UV printing on front panel

Powder coated steel case with plastic blowers

Remote control and door switch are optional

SA8 Series
Model	Voltage/ Frequency V/(Hz)	Motor input power (W)		Air Velocity (M/S)		Noise(dB)		Air Volume (M3/H)		Net Weight(KG)	Gross Weight (KG)	Unit Size (MM)	Packing Size (MM)
		Motor input power (W)		Air Velocity (M/S)		Noise(dB)		Air Volume (M3/H)
		Hi	Low	Hi	Low	Hi	Low	Hi	Low
FM-3509L-SA8	220-240/50	285	200	16	13	52	49	1100	900	13.5	14.5	945×232×225	1025X275X285
FM-3510L-SA8		300	215			52	49	1150	950	14.5	16	1030×232×225	1110X275X285
FM-3512L-SA8		370	270			53	50	1500	1200	16.5	18	1240×232×225	1320X275X285
FM-3515L-SA8		470	340			55	52	1900	1500	21.5	23.5	1535×232×225	1615X275X285
FM-3518L-SA8		550	400			57	55	2280	1800	24.5	27	1855×232×225	1935X275X285
FM-3520L-SA8		570	415			57	55	2400	1900	26.5	29.5	2010×232×225	2090X275X285
FM-4009L-SA8	220-240/50	370	300	20	16	57	54	1400	1000	13.5	14.5	945×232×225	1025X275X285
FM-4010L-SA8		400	320			57	54	1450	1050	14.5	16	1030×232×225	1110X275X285
FM-4012L-SA8		460	370			58	55	1900	1500	16.5	18	1240×232×225	1320X275X285
FM-4015L-SA8		600	480			61	58	2300	1900	21.5	23.5	1535×232×225	1615X275X285
FM-4018L-SA8		700	560			63	61	2850	2250	24.5	27	1855×232×225	1935X275X285
