Meihao commercial Centrifugal air curtain FM-SA5 series

Type:Ambient Air Curtain

Place of Origin:Guangzhou, P.R. China

Certification:CE, CB

Fan type:Centrifugal

Airflow:900-2850 m3/h

Packaging Details:Carton box with foam and PE bag

OEM/ODM:Available

Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

Ambient Centrifugal model

Centrifugal structure ensure high air velocity

Aesthetically pleasing 3D design provide better protection during transportation

Powder coated steel case with plastic blowers

Remote control and door switch are optional


SA5 Centrifugal Series   Steel Version (NEW)

Model

Voltage(V)/
  Frequency
   (Hz)

Motor Input Power
  (W)

Max Air Velocity (M/S)

Noise (dB)

Air Volume (M3/H)

Net Weight (KG)

Gross Weight (KG)

Unit Size (MM)

Carton Size (MM)

Hi

Low

Hi

Low

Hi

Low

Hi

Low

FM-3509L-SA5

220-240/50

220

180

16

13

52

49

1100

900

13.5

14.5

935×237×225

985X275X285

FM-3512L-SA5

270

220

53

50

1500

1200

16.5

18

1230×237×225

1280X275X285

FM-3515L-SA5

350

280

55

52

1900

1500

21.5

23.5

1525×237×225

1575X275X285

FM-4018L-SA5

400

320

57

55

2280

1800

24.5

27

1845×237×225

1895X275X285

FM-4009L-SA5

220-240/50

370

300

20

16

57

54

1400

1000

13.5

14.5

935×237×225

985X275X285

FM-4012L-SA5

460

370

58

55

1900

1500

16.5

18

1230×237×225

1280X275X285

FM-4015L-SA5

600

480

61

58

2300

1900

21.5

23.5

1525×237×225

1575X275X285

FM-4018L-SA5

700

560

63

61

2850

2250

24.5

27

1845×237×225

1895X275X285
